Description
This 2-3/16″ plastic flange bearing is a 4-bolt flange bearing that is manufactured from high-quality USDA and FDA approved natural UHMW. It’s manufactured to standard dimensions for easy replacement of cast or stainless steel bearings. 2-3/16″ plastic flange bearings are found in a wide range of food-grade, corrosive, abrasive, and medical applications, because of the properties of UHMW these bearings are self-lubricating and maintenance-free. Our standard 2-3/16″ 4-bolt flange bearings are capable of operating in temperatures up to 200F, we also supply high-temp plastic bearings that can operate in temperatures up to 600F. For additional information or to get a quote on 2-3/16″ plastic flange bearings contact our customer support team and we will be happy to assist you!
2-3/16″ Plastic Flange Bearing Dimensions
- Part #: 4FB-2-316
- Bore Size: 2-3/16″
- Bolt Size: 5/8″
- Dimension (A): 6-3/8″
- Dimension (B): 5-1/8″
- Dimension (C): 1-3/4″
- Max Speed (RPM): 85
- Max Radial Load (LBS): 3050
