Description
This 7307-B angular contact bearing is a high-precision 45-degree 35x80x21 bearing manufactured to ABEC 7 precision standards by AXIS. The contact angle on this type of bearing is the angle between the radial plane and a line that joins the two contact points between the inner and outer race. The higher the degree of the angle, the more increased the single-directional thrust capacity of the bearing. The AXIS 7307-B bearing separates itself from other brands by using high-quality metals, a bronze cage, and the superior ABEC 5 precision rating they are manufactured to. The more precise a bearing is, the better it performs in any given application. 7307-B angular contact bearings are typically found in applications such as agriculture, chemical facilities, utilities, and a range of general industrial applications. For additional information or to get a quote, please contact our customer support team and we will be happy to assist you!
7307-B Angular Contact Bearing Dimensions
- Bearing Size:7307B
- Dimension (d): 35mm
- Dimension (D): 80mm
- Dimension (B): 21mm
- Dynamic Load Rating: 7310 LBS
- Static Load Rating: 4550 LBS
- Limiting Speed (Grease): 7700 RPM
- Limiting Speed (OIL): 10000 RPM
