Csb209 Insert Bearing – 45Mm Bore, Eccentric Locking Design

Description

CSB209 bearing is a light-duty ball bearing insert made to C3 precision standards and utilizes set-screws to secure to a 45mm shaft. Our CSB209 insert bearing has several features: a wide inner-ring, steel retainer, anti-rotation device, and an inner ring and outer ring made from bearing grade steel to produce a high-quality and long-lasting bearing. Our CSB209 bearing is made to industry standards dimensionally for direct interchangeability with just about any brand. For additional information or to receive a quote on our CSB209 bearings, contact our customer service and, we will be happy to assist you!

CSB209 Bearing Dimensions

• Part #: CSB209
• Shaft Diameter (d): 45mm
• Setscrew Used: M8 x1
• Dimension (D): 85.0mm
• Dimension (Bi): 36.0mm
• Dimension (Be): 19.0mm
• Dimension (N): 9.5mm
• Dimension (M): 31.0mm
• Dimension (G): 8.0mm
• Dimension (T): 6.1mm
• Dynamic Load Rating (kN): 31.85
• Static Load Rating (kN): 20.80
• Weight (kg): 0.8
