Description
CSB40MFM202-10 stamped steel bearing is a 2-bolt flush mount flange bearing designed for light-duty industrial and agricultural applications. The superior quality stamped steel housing encases a performance C3 precision 5/8″ insert bearing that utilizes set screws for securing onto a shaft. CSB40MFM202-10 bearings are more economical than their cast counterparts but offer excellent performance in bearing applications; the two-bolt flange stamped steel housing allows for great mounting when the shaft is positioned perpendicular to the bearing. Utilizing two mounting holes, the CSB40MFM202-10 5/8″ bearing has incredible holding power, stability, and mounting position flexibility. Additionally, our CSB40MFM202-10 stamped steel bearing features a zinc plated housing for added protection against the elements in corrosive or outdoor applications. For more information or to get a quote on our flush mount CSB40MFM202-10 bearing, contact our customer support team, and we will be happy to assist you!
CSB40MFM202-10 Bearing Dimensions
- Bearing Unit Part #: CSB40MFM202-10
- Bearing I.D.: 5/8″
- Dimension (a): 3-3/16″
- Dimension (e): 2-33/64″
- Dimension (s): 9/32″
- Dimension (b): 2-21/64″
- Dimension (Bi): 0.875″
- Bolt Size: 1/4″
- Insert Bearing #: CSB202-10
- Housing #: 40-2-MFM
- Weight: 0.44 LBS
