Description
UEFT205-15 bearing is a 15/16″ bore two-bolt normal-duty flange bearing that utilizes a Tru-Loc device to secure to a 15/16″ shaft. UEFT205-15 flange bearings are designed for circumstances where the bearing is mounted to a surface perpendicular to the shaft axis and can fit in more space-restricted areas while still offering excellent stability with two mounting holes. Our superior UEFT205-15 bearing with a 15/16″ bore is equipped with a premium C3 precision insert bearing housed within a high-strength solid-base cast-iron housing. Additionally, our UEFT205-15 bearing has added features that improve the overall life and performance of the unit, such as; a steel retainer, wide inner-ring, anti-rotation device, and relubricating capabilities. UEFT205-15 bearings are commonly used in applications such as; construction equipment, agricultural equipment, forestry, aggregate, conveyor systems, and many more. Our UEFT205-15 bearing is dimensionally made to industry standards, meaning it interchanges with just about any brand out there. Contact our customer support team for further information or to get a quote on our UEFT205-15 bearings, and we will be happy to assist you!
UEFT205-15 Bearing Dimensions
- Part #: UEFT 205-15
- Shaft Diameter (d): 15/16″
- Dimension (A): 4.88″
- Dimension (E): 3.891″
- Dimension (I): 0.63″
- Dimension (G): 0.50″
- Dimension (L): 1.06″
- Dimension (S): 0.47″
- Dimension (B): 2.75″
- Dimension (Z): 1.44″
- Dimension (Bi): 1.3937″
- Dimension (N): 0.5630″
- Dimension (M): 0.780″
- Bolt Used: 3/8
- Dynamic Load Rating (LBS): 3,155
- Static Load Rating (LBS): 1,810
- Bearing Insert: UE 205-15
- Housing Number: FT 205
- Weight (LBS): 1.5
