Description
The concentric MB4XLSS metric bushing is manufactured for size 4XL guide wheels and is made from high-quality 303-grade stainless steel. MB4XLSS bushings are used as a component for mounting guide wheels and have a precision head-thickness tolerance of +/- 0.001″ to ensure optimal function and longevity. For more information or to get a quote, contact our customer support team, and we will be happy to assist you!
Concentric MB4XLSS Bushing Dimensions
- Part #: MB4XLSS
- For Wheel Size: 4XL
- Head Profile: Standard
- Adjustability: Concentric
- Head Size (B): 1.250″
- Overall Height (C): 1.555″
- Head Thickness (D): 0.565″
- Mounting Surface To Wheel Vee (E): 1.065″
- Wheel Mounting Diameter (F): 0.8657″
- Wheel Mounting Length (G): 0.990″
- Mounting Hole Diameter (H): 0.5512″
- Recommended Mounting Hardware: M12
